مبدل سریال به شبکه EZL-200F (اکسترنال)

توضیحات

and easily add Ethernet connectivity in their system. This product helps your RS232/422/485 device get network connectivity with just serial connection. Applying EZL-200F, not only you can reduce cost and risk, but also you can shorten development time to add the network capability. Because EZL-200F allows you to a overcome distance limitation of your serial communication system, you are able to remotely control and monitor the serial devices over the Internet. EZL-200F maintains strong popularity because of the high performance based on MIC RTOS, along with many attractive functions such as Multi Monitoring and SSLR.

Benefits & Features

1- RS232/422/485 to Ethernet Converter

2-  MIC (Embedded RTOS developed by ourselves)

3- Ethernet 10Base-T or 100Base-TX (Auto-Sensing)

4- 1 x RS232 (D-SUB 9pin Male, up to 115.2Kbps)

5- Multi-Monitoring in TCP server mode. (Maximum 8 channels)

6- Access Restriction : IP address filtering, Password

7- Security Protocols : SSL3.0/TLS1.0, SSH2.0(Management/Data)

8- Telnet COM Port Control Option (RFC 2217)

9- SSLR : simple router function

10-Flexible configuration and network communication by ‘AT Commands’ (patent)

11-Variety of monitoring status(debugging mode, ezConfig, Telnet)

12- 4 Communication modes (TCP server, TCP client, AT Command and UDP)

13-DHCP and PPPoE Firmware upgrade through Network and serial

14-  Powerful configuration software for Windows OS (ezConfig) Virtual COM Port Redirector for Windows OS (ezVSP)

15- Environmentally-friendly RoHS compliant
